Engine |
Four-stroke, liquid-cooled, DOHC, four valves per cylinder, inline-four |
Displacement |
1,043cc |
Bore x Stroke |
77.0 x 56.0 mm |
Compression Ratio |
11.8:1 |
Fuel System |
DFI® with four 38mm Keihin throttle bodies, oval sub-throttles |
Ignition |
TCBI with digital advance |
Transmission |
Six-speed |
Final Drive |
X-ring Chain |
Rake/Trail |
24.5 deg / 4.0 in. |
Frame Type |
Aluminum Backbone |
Front Tire Size |
120/70 ZR17 |
Rear Tire Size |
190/50 ZR17 |
Wheelbase |
56.9 in. |
Front Suspension / wheel travel |
41 mm inverted cartridge fork with stepless compression and rebound damping, adjustable spring preload / 4.7 in. |
Rear Suspension / wheel travel |
Horizontal monoshock with stepless rebound damping, remotely adjustable spring preload / 5.4 in. |
Front brakes |
Dual 300mm petal-type rotors with radial-mount four-piston monobloc calipers and ABS |
Rear brakes |
Single 250mm petal-type rotor with single-piston caliper, with ABS |
Fuel Capacity |
5.0 gal. |
Seat Height |
32.3 in. |
Curb Weight |
509.4 lbs. |
Overall length |
82.9 in. |
Overall width |
31.1 in. |
Overall height: (Wndscrn Down/UP) |
46.1 / 48.4 in. |
Color(s) |
Candy Lime Green, Candy Cascade Blue |
Warranty |
12 Months |
Good Times™ Protection Plan |
12, 24, 36, 48 months |
